Innovex Uphole is designed for general blasting applications in underground mines, quarries, and construction with wet or dry holes. Innovex Uphole is not for use in the presence of sulphide reactive ground or elevated ground temperatures.
Innovex Uphole may be loaded at varying densities to achieve energies that optimize fragmentation distribution and minimise perimeter overbreak. The Innovex Uphole dual salt formulation is a product demonstrated to generate very low levels of post blast fume.
| Property | Unit | Base Emulsion | Gas Sensitized Emulsion | |||
| Average Inhole Density | g/cm³ | 1.47 to 1.51 | 0.90 | 1.00 | 1.15 | 1.20 |
| Velocity of Detonation | m/sec | 4116 | 4497 | 5071 | 5260 | |
| Relative Weight Strength | RWS | 67 | 73 | 84 | 90 | |
| Relative Bulk Strength | RBS | 75 | 91 | 120 | 135 | |
Velocity of Detonation, Relative Weight and Bulk Strengths calculated using the IPX code at a density of 1.20 g/cm³ and a cut-off pressure of 100 MPa relative to ANFO at a density of 0.80 g/cm³.
Actual in field velocity of detonation will vary and is dependent on hole diameter and confinement.
Innovex Uphole is compatible with most non-electric and electronic detonator systems.
Use of detonating cord with Innovex Uphole may influence blast outcomes.
Maximum hole depth depends on product selection, hole diameter, product densities, critical void space and the presence of water. Please contact a BME Technical Representative for additional guidance and site specific calculations using BME’s DensDepth program.
This product may be used in ground temperatures from 0 ° to a maximum of 65 °C. If the application requires use outside of this temperature range please contact a BME Technical Representative for additional guidance.
This product is not formulated for use in reactive ground. Reactive ground is typically characterised by the presence of sulphide mineralization. If the application requires use in known reactive ground, or in untested sulphide bearing ground, please contact a BME Technical Representative for additional guidance.
The recommended maximum sleep time is 21 days. Sleep time is dependent on factors such as hole diameter, density, ground water conditions and initiation system. If the application requires longer in-hole sleep time, please consult with a BME Technical Representative for guidance.
Product Classification
Authorised Name: Innovex Uphole - Base Emulsion
Correct Shipping Name: Ammonium Nitrate Emulsion
Classification: 5.1
UN Number: 3375
Authorised Name: Innovex Sensitizing Agent
Correct Shipping Name of System Components: Nitrates, Organic, Aqueous solution, N.O.S
Classification: 5.1
UN Number: 3219
Product Classification of Finished Sensitized Explosive Product
Authorised Name: Innovex Uphole
Correct Shipping Name: Explosive, Blasting
Classification: 1.1D
UN Number: 0241
In case of emergencies, click here to contact our team for assistance.
